Light Sources:
1x 100W Beam Light
Working life: 20000 hours
Color temperature :10000±500K
Color wheel: 14+1, 3200K single color wheel
Electronic strobe: 1~25Hz
Prism1: 16+24 (Ring Prism) and 6 (Line Prism)
Prism2: 16+24 (Ring Prism)
Static gobo wheel, 22 kinds of effect, macro effect modes.
Beam Angle: 1.5°
Power Consumption: 120±5%W
Power Voltage: AC 100-240V, 50/60Hz
Dimension: 360*260*626mm
Net Weight: 25 Kg
Flight case packing 2in1 size:755*447*835mm
Gross weight: 83.7Kg
Carton package 1in1 size: 750*375*470mm
Gross weight: 28.3Kg
Maximum number of connections:
16 units (230V, 50Hz) 2.5mm＆#178; power cable
8 units (120V, 60Hz) 2.5mm＆#178; power cable
Control:
DMX Channel: 16 / 19CH
Control Modes: DMX512/Master-Slave/Auto Run/Music/RDM
Pan/Tilt:
Pan/Tilt: 540°/ 270°
Pan/Tilt Resolution: 8/16 bit
Construction:
Display: TFT 1.8 inch Display
The font can be reversed 180°
Data In/Out socket: 3-pin XLR sockets
Power Socket: Power con in/out
Protection Rating: IP65
Features:
100W Creative Laser lamp module, more than 20000 hours running time
Low temperature with low noise fan, super low noise.
Variable strobe effects
Magnetic encoding positioning system, accurate positioming.
Light Sources:
1x 100W Beam Light
Working life: 20000 hours
Color temperature :10000±500K
Color wheel: 14+1, 3200K single color wheel
Electronic strobe: 1~25Hz
Prism1: 16+24 (Ring Prism) and 6 (Line Prism)
Prism2: 16+24 (Ring Prism)
Static gobo wheel, 22 kinds of effect, macro effect modes.
Beam Angle: 1.5°
Power Consumption: 120±5%W
Power Voltage: AC 100-240V, 50/60Hz
Dimension: 360*260*626mm
Net Weight: 25 Kg
Flight case packing 2in1 size:755*447*835mm
Gross weight: 83.7Kg
Carton package 1in1 size: 750*375*470mm
Gross weight: 28.3Kg
Maximum number of connections:
16 units (230V, 50Hz) 2.5mm＆#178; power cable
8 units (120V, 60Hz) 2.5mm＆#178; power cable
Control:
DMX Channel: 16 / 19CH
Control Modes: DMX512/Master-Slave/Auto Run/Music/RDM
Pan/Tilt:
Pan/Tilt: 540°/ 270°
Pan/Tilt Resolution: 8/16 bit
Construction:
Display: TFT 1.8 inch Display
The font can be reversed 180°
Data In/Out socket: 3-pin XLR sockets
Power Socket: Power con in/out
Protection Rating: IP65
Features:
100W Creative Laser lamp module, more than 20000 hours running time
Low temperature with low noise fan, super low noise.
Variable strobe effects
Magnetic encoding positioning system, accurate positioming.
Light Sources:
1x 100W Beam Light
Working life: 20000 hours
Color temperature :10000±500K
Color wheel: 14+1, 3200K single color wheel
Electronic strobe: 1~25Hz
Prism1: 16+24 (Ring Prism) and 6 (Line Prism)
Prism2: 16+24 (Ring Prism)
Static gobo wheel, 22 kinds of effect, macro effect modes.
Beam Angle: 1.5°
Power Consumption: 120±5%W
Power Voltage: AC 100-240V, 50/60Hz
Dimension: 360*260*626mm
Net Weight: 25 Kg
Flight case packing 2in1 size:755*447*835mm
Gross weight: 83.7Kg
Carton package 1in1 size: 750*375*470mm
Gross weight: 28.3Kg
Maximum number of connections:
16 units (230V, 50Hz) 2.5mm² power cable
8 units (120V, 60Hz) 2.5mm² power cable
Control:
DMX Channel: 16 / 19CH
Control Modes: DMX512/Master-Slave/Auto Run/Music/RDM
Pan/Tilt:
Pan/Tilt: 540°/ 270°
Pan/Tilt Resolution: 8/16 bit
Construction:
Display: TFT 1.8 inch Display
The font can be reversed 180°
Data In/Out socket: 3-pin XLR sockets
Power Socket: Power con in/out
Protection Rating: IP65
Features:
100W Creative Laser lamp module, more than 20000 hours running time
Low temperature with low noise fan, super low noise.
Variable strobe effects
Magnetic encoding positioning system, accurate positioming.
